The Solution
Real-Time RFID Validation Without Physical Tunnels
The Lyngsoe RFID Tunnel is a standardized and configurable solution designed for modern warehouse and logistics operations. It enables automated verification of carton contents—regardless of size—across both inbound and outbound flows.
Unlike traditional RFID tunnels, this solution delivers high-performance validation without adding physical complexity. With no need for shielding or physical tunnel structures, it offers a simpler, more flexible approach compared to conventional solutions. It ensures that what your systems say is in the box matches what is moving through your warehouse—helping you maintain accurate, reliable inventory at all times.
Designed for high-speed operations, the system enables rapid and reliable reading even in demanding conveyor environments, supporting efficient throughput without compromising accuracy.
Get in Touch
The Benefits
Measurable Operational Impact
Even small picking, packing, or receiving errors can create costly downstream issues.
The Lyngsoe RFID Tunnel addresses this by introducing automated, real-time verification:
- Inbound: Confirms received SKU quantities and validates labeling accuracy at goods receipt
- Outbound: Ensures every carton contains the correct SKUs, correct quantities, and is linked to the correct customer order before shipment
The result is fewer shipping errors, improved customer satisfaction, and higher confidence in inventory data.
Simple and Cost-Efficient deployment
The Lyngsoe RFID Tunnel is designed to remove the typical barriers associated with RFID tunnel deployments while fitting seamlessly into existing warehouse environments.
A key advantage is that no shielding or physical tunnel structures are required, reducing both complexity and cost. As a non-intrusive, stand-alone unit, the system can be mounted directly on or above existing conveyors and installed without structural changes or dedicated infrastructure—allowing you to upgrade your operation without redesigning it.
This makes the solution ideal for both new facilities and retrofitting them into live operations.
This means:
- Faster deployment
- Lower installation costs
- Minimal disruption to ongoing operations
Global Service and Lifecycle Support
The RFID Tunnel is supported by Lyngsoe’s global service program, ensuring long-term performance through expert support and comprehensive lifecycle services.
Performance Highlights
Under standard conditions and without system tuning, the solution delivers reliable, high-speed performance:
| Parameter | Performance |
| Conveyor speed (max) | 1.6 m/s (315 ft/min) |
| Minimum box spacing | 400 mm (16 inches) |
| Max. SKUs per carton | Up to 350* |
| Verification accuracy | > 99.9% |
*Configurations above 50 SKUs per carton may require system tuning for specific use cases.
System Components
The Lyngsoe RFID Tunnel combines proven hardware with flexible configuration:
- RFID Reader: High-performance reader for consistent and reliable tag capture
- RFID Antenna(s): Configurable setup to ensure full coverage across the conveyor width
- Barcode Scanner (optional): Matches carton barcodes with RFID-verified contents
- Photosensor (optional): Enables precise carton detection and read triggering
Software
The embedded software is designed for real-time performance and ease of use:
- Embedded Stand-Alone Design: Fully self-contained—no external controllers required
- Real-Time Singulation Algorithm: Optimizes read accuracy and throughput based on flow conditions
- Cross-Read Suppression: Ensures only tags within the target carton are read, eliminating interference from nearby items
- Configuration Interface: Simple setup of environmental parameters and ERP/WMS data formats
Triggers
- Photosensor: Automatically detects cartons and initiates RFID reading
- TCP/IP: Enables read-on-demand functionality via network communication
Interfaces
The system integrates smoothly with existing IT and automation landscapes:
- ERP / WMS Interface: Sends verified RFID data directly to business systems
- PLC Interface: Supports communication with conveyor and machine control systems
- Supported Protocols: MQTT, OPC-UA, TCP/IP, EPCIS, JSON*
*Industry-standard protocols for real-time and event-driven data exchange
Our Success Stories
See how we help customers improve visibility, efficiency, and operational performance across complex logistics operations.
Stay updated
Get the latest news, product updates, and insights delivered to your inbox.
What is an RFID tunnel used for in warehouse operations?
An RFID tunnel is used to automatically verify the contents of cartons, totes, or shipments as they move through warehouse conveyor systems. It helps distribution centers and logistics operations validate SKUs, quantities, and shipment accuracy in real time without manual scanning. RFID tunnel systems are commonly used to improve inventory accuracy, reduce shipping errors, and automate inbound and outbound verification processes.
How does RFID carton verification improve supply chain accuracy?
RFID carton verification enables real-time validation of products inside cartons before they are received or shipped. By automatically confirming SKU quantities and order accuracy, companies can reduce picking and packing errors, prevent incorrect shipments, and improve inventory reliability across warehouse and distribution operations.
Do all RFID tunnel systems require shielding and physical tunnel structures?
Traditional RFID tunnel systems often rely on shielding and physical tunnel enclosures to control read zones and prevent interference. The Lyngsoe RFID Tunnel takes a different approach by eliminating the need for physical tunnel structures while still delivering highly accurate carton validation in conveyor-based environments. This reduces deployment complexity, lowers installation costs, and makes integration into existing warehouse operations faster and more flexible.
Can RFID tunnel solutions integrate with WMS, ERP, and warehouse automation systems?
Yes. the RFID tunnel systems from Lyngsoe are designed to integrate directly with warehouse management systems (WMS), ERP platforms, PLCs, and conveyor controls. The Lyngsoe RFID Tunnel supports industry-standard protocols such as MQTT, OPC-UA, TCP/IP, EPCIS, and JSON, enabling seamless real-time communication between RFID infrastructure and existing supply chain and warehouse automation systems.
What are the advantages of RFID tunnels compared to barcode scanning?
RFID and barcode technologies are often used together in modern warehouse operations rather than as direct replacements for one another. Barcode scanning remains highly effective for item-level identification and low-cost workflows, while RFID adds automated, high-speed validation capabilities for cartons, pallets, and conveyor-based operations. Unlike traditional barcode scanning, RFID technology can read multiple tagged items simultaneously without requiring line-of-sight scanning. This enables warehouse operations to automatically validate entire cartons while moving through the conveyor flow, reducing manual handling and improving throughput. Many supply chain organizations use a hybrid approach where barcodes and RFID complement each other. For example, barcode scanners can identify carton IDs while RFID verifies the carton contents in real time. The Lyngsoe RFID Tunnel supports this approach through optional barcode integration, enabling accurate and scalable verification for high-volume logistics environments.
What should companies look for in an end-to-end RFID solution provider?
hen evaluating RFID solution providers, companies should look beyond hardware specifications and consider implementation experience, integration capabilities, scalability, and long-term support.
Successful RFID deployments often require seamless integration into warehouse operations, ERP/WMS platforms, and automation systems while maintaining high read accuracy in demanding environments. Lyngsoe provides integrated RFID solutions designed for warehouse automation and supply chain visibility, including RFID readers, tags, antennas, software, integration into ERP, WMS, and automation platforms, as well as global service and support.
With more than 15,000 RFID installations worldwide, Lyngsoe has extensive experience delivering reliable RFID solutions for complex, high-throughput operations.
What support should you expect from an RFID solution provider?
RFID systems are often critical to daily warehouse and logistics operations, making long-term service and support an important part of any deployment. Companies should expect support throughout the entire solution lifecycle, including deployment, integration, optimization, maintenance, and ongoing technical assistance. Lyngsoe supports customers through a global service and lifecycle program designed to ensure stable performance and long-term operational reliability. This helps supply chain organizations maintain uptime, adapt to changing operational requirements, and maximize the value of their RFID investment over time.
How accurate are RFID tunnel systems?
Modern RFID tunnel systems are designed to deliver highly accurate carton and shipment verification in fast-moving warehouse environments. Read accuracy depends on factors such as tag quality, carton composition, conveyor speed, and system configuration, but advanced RFID solutions can achieve verification accuracy above 99%. The Lyngsoe RFID Tunnel is designed for reliable, real-time validation in both inbound and outbound flows, with verification accuracy above 99.9% under standard conditions. Features such as intelligent read algorithms and cross-read suppression help ensure that only tags within the target carton are captured, supporting accurate inventory data and reducing shipping and fulfillment errors.
Can RFID tunnels handle high-speed conveyors?
Yes. RFID tunnel systems are commonly designed for high-throughput warehouse and logistics operations where cartons move continuously through conveyor flows. Advanced RFID solutions use optimized antenna configurations and real-time read algorithms to maintain high accuracy even at higher conveyor speeds.
The Lyngsoe RFID Tunnel supports conveyor speeds up to 1.6 m/s (315 ft/min) under standard conditions while maintaining reliable verification performance. This enables supply chain operations to automate carton validation without slowing throughput or compromising operational efficiency.
How do you deploy RFID in existing warehouses?
Modern RFID solutions can often be deployed into existing warehouse environments without major infrastructure changes. Many companies implement RFID as part of a phased automation strategy, allowing them to improve inventory visibility and process validation while maintaining ongoing operations. The Lyngsoe RFID Tunnel is designed for simple integration into live warehouse environments. As a non-intrusive, stand-alone solution, it can be mounted directly on or above existing conveyors without requiring physical tunnel structures or shielding. This helps reduce installation complexity, minimize operational disruption, and accelerate deployment timelines.
